The US Coast Guard Captain of the Port (COTP) in New Orleans has recently issued a warning to vessels concerning compliance with 33 CFR 156.170, which requires each transfer pipe system on board a vessel to be tested under static liquid pressure at least 1.5 times the maximum allowable working pressure annually. During Port State Control (PSC) examinations, the COTP has noted that approximately 30% of vessels are not in compliance. In most cases, the PSC Officers found that the vessels had tested the systems with air rather than with liquid which makes the test null and void. In addition, several vessels were not able to provide written records of the date and result of the most recent test and inspection of bunker lines/transfer systems as required by 33 CFR 155.820.
The Coast Guard has not yet begun to issue fines or penalties for non-compliance. However, vessels do run the risk of having their bunkering operations stopped until the proper tests are conducted.
Quoted from: https://www.steamshipmutual.com/publications/Articles/USBunkerLineTest0708.html[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width=”1/2″][vc_single_image image=”39831″ img_size=”large” alignment=”center”][/vc_column][vc_column width=”1/2″][vc_single_image image=”39832″ img_size=”large” alignment=”center”][/vc_column][/vc_row][vc_row][vc_column]
HP-25/35 Pneumatic Hydrostatic Test Pump
The HP-25/35 model is a pneumatic driven hydrostatic test pump with a pressure range of 350 to 3500 PSI, with a flow rate of 2.5 GPM. Lightweight at 50 pounds and portable this unit is ideal for testing in small confined spaces and remote locations. Designed for testing oil, gas, water and steam lines; such as onboard ships, oil rigs and refineries. This unit has the ability to start/stop while under pressure, and is capable of handling various fuels, oils and chemicals.
Literature
Description
FH3 Fire Hose Tester 3 GPM up to 500 PSI
The FH3 is our most popular fire hose tester on the market; an electric powered hydrostatic test pump offering 3 GPM up to 500 PSI. Designed to safely test fire hose up to 6″ in diameter. Triplex ceramic plunger pump with an inner oil bath, ensuring long life and increased stability. Heavy duty manifold with FOUR independently controlled stainless steel ballvalves. NO WILD LINES – unique to the RICE Hydro line of fire hose testers, a ballvalve strategically placed on the inlet piping allows the user to fill with “LARGE VOLUME at LOW PRESSURE” and test with “LOW VOLUME at HIGH PRESSURE”, eliminating the elements that may cause wild lines. Virtually indestructible, enclosed in a rugged roll cage of welded heavy gauge steel. “Built to Suit” special order and custom options are available to fit your specific testing needs.
-
3 GPM up to 500 PSI
-
1 HP Electric Motor, TEFC, 110/220V, 50 or 60 Hertz capability
-
Four independently controlled outlet ballvalves, with NST couplings
-
Stainless Steel liquid-filled 0 - 600 PSI gauge, ensures accurate readings
-
Adjustable pressure regulator from 50 - 500 PSI
-
Rugged roll cage construction, protects pump from damage
-
Medium duty 4" casters included, anti-friction roller bearing, Plexite phenolic wheel
-
5 Year Warranty from Manufacturers Defect
-
Pump weight: 158 pounds Dimensions: 28 X 23 X 19 Shipping: 175 pounds
All RICE units can be "Built to Suit", contact the factory for special order options or custom build to meet your specific test requirements.
